SKU 0008
$1 100.00
Size
In stock
1
Product Details

FULL SPECS & FEATURES

Basic Features- Bedrooms : 3, Baths : 2.5, Stories: 2, Garages: 0
Dimension- Depth : 43', Height : 22' 8", Width : 30'
Area- Total : 2063 sq/ft, Main Floor : 1056 sq/ft, Porch : 206 sq/ft, Upper Floor : 1007 sq/ft
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
 Ceiling- Main Ceiling : 9', Upper Ceiling Ft : 9'
Roof- Primary Pitch : 0:0, Roof Framing : Truss, Roof Type : Asphalt
Exterior Wall Framing- Exterior Wall Finish : Stone/Siding, Framing : 2 x 6
Bedroom Features- Upstairs Bedrooms, Upstairs Master Bedrooms, Walk In Closet
Kitchen Features- Eating Bar, Kitchen Island, Walk In Pantry Cabinet Pantry
Additional Room Features- Family Room Keeping Room, Great Room Living Room, Main Floor Laundry
Lot Characteristics- Suited For Narrow Lot
Outdoor Spaces- Covered Front Porch, Covered Rear Porch


WHAT'S INCLUDED IN THIS PLAN SET

See a sample plan set


    Exterior Elevations (front, rear, left & right sides) typically include:
    • Floor and ceiling heights
    • Dimensions of standard windows
    • Dimensions of roof overhangs
    • Location of all needed flashings (mention of “typical” in most cases)
    • Height and location of foundation indicated in dashed lines
    • Type of finishing and textures (we write siding, horizontal or vertical but not the company)
    • Dimension and height of chimney (dimensions yes but the height is determined by the local building code)
    Foundation plans typically include:
    • All exterior and interior dimensions
    • Thickness of foundation walls (if variable)
    • All the structures needed to hold the first level, columns with load applications, beam sizes, variations in floor joists and their exact location. (The load application is not present. Same for the beam, we mention they are but not the size because this can be changed as per manufacturer)
    • Location of stairwell
    • Location and sizes of windows
    • Location and dimensions of footings (where applicable and required)
    Floor plan(s) typically include:
    • All interior and exterior dimensions (included but not as a schedule)
    • Location and sizes of doors and windows
    • Indication of the structure above (second floor or roof)
    • Indication of details that are available on other pages
    Roof plans typically include:
    • Location of all the different trusses needed
    • The general overcharge of the roof compared to the floor footprint underneath
    Building cross-section(s) and truss details typically include:
    • All the different floor and ceiling heights
    • Dimensions and design of trusses
    • Dimensions and details of overhand
    • Roof pitch on all truss sections
    Construction details typically include:
    • Roof sections
    • Sections of concrete wall with wood connection
    • Section of walls with particulars called out
    • Section of concrete porch and connection with wood frame
    • Foundation particulars in the garage entrance
    • Components of certain types of walls (ex: between garage and living quarters)
    Typical wall sections typically include;
    • All the details and components needed in the construction of a house, including window section in a typical wall, connection between floor and exterior wall with their components, type of beam used.
    • Note: This plan does not include HVAC, electrical and plumbing.
